eVO 高階數位影像裂隙燈
產品說明
Microscope
| eVO500 | |
| Microscope | Galilean |
| Magnification | 5 step: 6.5X, 10X, 16X, 25X, 40X |
| Eyepiece | WF 12.5x, focusable with retractable eye guards, diopter adjustment ± 5 mm and diopter lock |
| Interpupillary distance | 49 - 78 mm |
| Slit length | 0 - 13.5 mm |
| Slit apertures | 0.6, 5.8, 9, 13.5 mm 1.5 - 12.0 mm continuous |
| Slit rotation | 0 - 180° |
| Filter | Red free, Cobalt blue, Heat absorbing |
| Longitudinal movement (in/out) | 100 mm |
| Lateral movement (left/right) | 107 mm |
| Vertical movement (up/down) | 30 mm |
| Chin rest range | 80 mm |
| Light source | 6V 20W Halogen |
| Digital imaging | --- |
| Optional accessories | Tonometer; Motorized Table; Beam splitter and CCD camera |
| eVO500D | |
| Stand | Galilean |
| Magnification | 5 step: 6.5X, 10X, 16X, 25X, 40X |
| Eyepiece | WF 12.5x, focusable with retractable eye guards, diopter adjustment ± 5 mm and diopter lock |
| Interpupillary distance | 49 - 78 mm |
| Slit length | 0 - 13.5 mm |
| Slit apertures | 0.6, 5.8, 9, 13.5 mm 1.5 - 12.0 mm continuous |
| Slit rotation | 0 - 180° |
| Filter | Red free, Cobalt blue, Heat absorbing |
| Longitudinal movement (in/out) | 100 mm |
| Lateral movement (left/right) | 107 mm |
| Vertical movement (up/down) | 30 mm |
| Chin rest range | 80 mm |
| Light source | 6V 20W Halogen |
| Digital imaging | iVu S5 5MP integrated digital camera module with on-device capture button and SD card; USB v2.0 and HDMI (1080p) ports |
| Optional accessories | Tonometer; Motorized Table |
